High Pressure 3kw 4hp Car Washer Cleaning Machine 24mm Hollow Shaft 50Hz Frequency Three-Phase Waterproof Protect Feature

  • High Pressure 3kw 4hp Car Washer Cleaning Machine 24mm Hollow Shaft 50Hz Frequency Three-Phase Waterproof Protect Feature
  • High Pressure 3kw 4hp Car Washer Cleaning Machine 24mm Hollow Shaft 50Hz Frequency Three-Phase Waterproof Protect Feature
Tempat asal CINA
Nama merek ZOZHI
Sertifikasi CE,CCC,ISO9001
Nomor model HS100L2-4
Kuantitas min Order 2 buah
Harga USD127piece
Kemasan rincian kasus CTNS/Veneer
Waktu pengiriman 14 hari kerja
Syarat-syarat pembayaran T/t, l/c
Menyediakan kemampuan 10.000 lembar per30 hari
Detail produk
Kecepatan asinkron 1450rpm Kelas isolasi F
Lampiran IP55 Suhu sekitar 40 ° C.
Ukuran bingkai 100 Kelas Perlindungan IP55
Warna dapat disesuaikan Kekuatan 4HP/3KW
Tugas S1 (lanjutan) Torsi Tinggi
ketinggian ≤1000m Frekuensi nilai 50Hz/60Hz
Jenis pemasangan Kaki terpasang
Menyoroti

3kw high pressure car washer

,

4hp three-phase cleaning machine

,

24mm hollow shaft induction motor
Anda dapat mencentang produk yang Anda butuhkan dan berkomunikasi dengan kami di papan pesan.
Tinggalkan pesan
Deskripsi Produk
High Pressure 3kw 4hp Car Washer Cleaning Machine 24mm Hollow Shaft 50Hz Frequency Three-Phase Waterproof Protect Feature

This industrial-grade 4HP AC induction motor (22KW) is engineered for reliable, high-torque performance in demanding applications. Designed with a precise 1400RPM speed and a standardized three-phase 380V/50Hz power supply, its key feature is the integrated 24mm hollow shaft. This design makes it an ideal, direct-drive solution for water pumps, gearboxes, conveyors, and various machinery requiring efficient power transmission.

Specification
Brand Name ZOZHI
Type Asynchronous Motor
Phase Three phase
Frequency 50hz/60hz
Efficiency IE 1
Protection class IP55
Certification CCC/CE/ISO9001
Housing Aluminium
Insulation Class ClassF
Duty S1 (continuous)
Motor Bearing C&U
Flange Size 87/61mm
Overall Dimension
High Pressure 3kw 4hp Car Washer Cleaning Machine 24mm Hollow Shaft 50Hz Frequency Three-Phase Waterproof Protect Feature 0 High Pressure 3kw 4hp Car Washer Cleaning Machine 24mm Hollow Shaft 50Hz Frequency Three-Phase Waterproof Protect Feature 1
Frame Size Flange Frame M N S A AC B H HC L K
90L 75/87 90/61 7 140 238 125 90 220 270 9.5
100L 75/87 90/61 9 160 255 140 100 240 315 11
112M 75/87 90/61 9 216 326 140 132 320 330 11
132S 75/87 90/61 9 216 326 140 132 320 370 12
Technical Specifications
Model Power Speed (RPM) Efficiency Current (A) Weight (kg) Voltage (V) Starting Current (A)
Single Phase 50Hz/2-pole
HSL90L1-2 2.5HP/1.8KW 2850 0.95 65 50 230 12.7
HSL90L2-2 3HP/2.2KW 2840 0.99 72 60 400 13.4
HSL100L2 3HP/2.2KW 2850 0.96 74 85 400 15.3
HSL132S1-2 5.5HP/4KW 2920 0.88 86 - 400 21.8
HSL132M2-2 20HP/15KW 2920 0.87 89.2 - 400 41
Three Phase 50Hz/2-pole
HS90L1-2 3HP/2.2KW 2820 0.86 78 - 400 4.9
HS90L2-2 4HP/3KW 2820 0.80 83 - 400 8.6
HS100L1-2 4HP/3KW 2840 0.83 81 - 400 6.6
HS100L2-2 5.5HP/4KW 2850 0.86 84 - 400 11.6
HS132S1-2 7.5HP/5.5KW 2900 0.86 84 - 400 15.4
HS132M2-2 20HP/15KW 2920 0.88 86 - 400 28
Three Phase 50Hz/4-pole
HS90L1-4 2HP/1.5KW 1400 0.82 78 - 400 3.2
HS90L2-4 3HP/2.2KW 1400 0.80 81 - 400 6.9
HS100L1-4 3HP/2.2KW 1420 0.80 81 - 400 5.1
HS112M1-4 4HP/3KW 1420 0.80 82 - 400 12.4
HS132S1-4 7.5HP/5.5KW 1430 0.90 85 - 400 17.8
HS132M2-4 15HP/11KW 1430 0.90 87 - 400 26
HS160M1-4 20HP/15KW 1450 0.86 89 - 400 29
